Solder reflow fixtures are designed and built for supporting many types of components.  These simple weights, cradles, support blocks, and other solutions are made to target a single component at a time.  Each in turn reduces the need for making multiple fixtures for different assemblies.  In many cases making a single solution for a large number of cases is a fast way to save money, cut setup time, and increase change over flexibility.

Racks for elevating printed circuit boards from the machine conveyor belt allow for reflowing of the surface mounted components especially in the case where double sided technology and through hole in paste are used.  The low mass of these racks will reduce the number of machine profile changes.  The adjustable bar allows for various assemblies to be run at the same time.  Look for this and many other related solutions to help you advance your business.

Lead formers and cutters are a necessary part of the Printed Circuit Assembly operation and is one of the most costly to manufacturers if not managed well.  Multiple pattern cutter plates, located on a single actuator mechanism, are an ideal way to save space and to reduce setup time.  Making lead formers small, simple to use, and simple to set up is our specialty.  Call us for solutions that have eluded you and we will be glad to help you.

Hand solder and add on type fixtures are needed to provide support to components while being assembled to the Printed Circuit Board.  These tools are handy to have and provide a measurable increase in output.  The main advantage of having these fixtures is component position and alignment in respect to the printed board and other components on the same assembly.  The ergonomic advantage is to the operators where by it measurably reduces the repetitive task fatigue.

Many kinds of pallets are available weather it is used for selective wave, auto test, flying probe test, X-ray test, stenciling, gluing, and component placement.  These pallets hold the board firmly in place and clear the moving parts of your equipment.  If you don’t see your needs listed please contact us we are sure we can help you reach a very well made solution.

Test related solutions are also available and can help in the processing of assemblies and will reduce damage due to machine or operator miss handling.  Mechanical solutions to functional and in-circuit testers are available as needed.  These solutions are a collaborative effort, joining our mechanical knowledge with your electronic test needs.

New emerging technologies such as press fit (press-in or compliant pins) connectors are always a challenge for assembly centers, this is now made simple with the use of nests and auxiliary support blocks.  Board flexing is a leading cause of fractured joints, with these fixtures both board and part damage are eliminated.  These fixtures are sturdy and can take repeated usage over the life of your product.

Many solutions require a unique approach, this is a holder for pneumatic and electric torque drivers (zero gravity balancer) which also doubles as an anti rotation holder.  These balancers are very versatile and are designed individually to fit any work-station even inside a clean room.  Ergonomically designed and can be made for fast setups and changes.

Other types of tools are a must for any assembly operation.  Depicted here is an insertion type tool used to install a cover over a radio frequency interference fence.  This pneumatically actuated installer has four jaws which grip and shape the cover to clear the fence edges while loading.  This tool and many other unique designs are not found in any catalog and we at Qminx would be happy to provide for you.
